Drive Support
- Up to 16 3.5” drives
- 6/12 Gb SAS, 6 Gb SATA HDD and SSD
- Supports any mix of SAS and SATA drives simultaneously in the same enclosure
External I/O Ports (per controller)
Single (sS)/Dual (sD), IN/OUT 12G SAS-wide port over SFF-8644 per controller.
SAS HBA
Follow Vess J3000 compatibility list
RAID Storage Subsystem
Vess R3000/Vess A6000/Vess A7000
Expander Management Features
- Self-configuring expander supports full SAS domain topology management
- End Device Frame buffering (aggregate bandwidth over multiple slow devices e.g. 6G and 3G)
- Smart cable support to detect cable type and tune PHY automatically for maximum reliability
- SMP-SAS Management Protocol
- In-band access to Expander and PHY information
- Statistic counters
- SES EM-SES Enclosure Management (ANSI T10 SES 2 Compliant)
- SCSI SES command set over virtual SSP device
Management Interfaces
- LED status indicator support for drives, FRU and enclosure environmentals
- In-band SES enclosure management alerts user to out of spec operation: thermal condition, voltage condition or component failures, protecting data and hardware
- Full subsystem management CLI through out-of-band RS232 serial port
Enclosure Protocol and Management
ANSI T10 SES 2, SMP (SES over in-band SAS)
VPD (Vital Product Data) on Chassis and FRUs
Operation Temperature
Operational: 5° to 35°C, Non-Operational: -40° to 60°C
Power Supply
CRPS 550W ; Eflciency 80PLUS Certified Redundant PSU
Voltage
AC: 100-240VAC; DC: 180-320VDC Auto-Ranging
Current (Maximum)
< 8A@100-240VAC@full load; < 8A@180-320VDC@full load
Power Conversion Efficiency
>80% @ 110V (>20% load), >80% @ 240V (>20% load) Temperature Range
Humidity
Operational: 20% to 80% (Non-Condensing), Non--Operational: ~ 95% (Non-Condensing)
Acoustic Noise Levels
<60dB, 25℃
Shock
Operational: 5G, 11 ms duration, Non-Operational: 30G, 11ms duration
Vibration
Operational: 0.2G, 5 to 500Hz (sine wave) ; 0.41G, 3-10-200-500Hz (Random)
Non-Operational: 1G, 5 to 500Hz (sine wave) ; 2.256G, 5-80-350-500Hz (Random)
Safety and Emission Certification
EMC Class A: CE, FCC, VCCI, BSMI, RCM
Safety: IEEE CB, NTRL
Dimensions
131mm x 446.7mm x 507mm (5.2” x 17.6” x 19.96”)
